Clear Headlight Film with Air Channel Paper Liner

Clear Headlight Film with Air Channel Paper Liner

The Clear Headlight Film with Air Channel Paper Liner is a clear headlight protection film that shields your lenses without changing how they look. It stays see-through and glossy and lets nearly all your light through, while taking the stone chips, grit, bug splatter, and sun damage that would otherwise cloud and yellow the lens.

It goes on dry. Air-release channels let trapped air escape as you squeegee, so it lays down without bubbles, and the paper backing makes it easy to line up before it grips. The clear top coat is self-healing, so light scratches fade out with a little heat. Apply it over headlights, fog lights, taillights, side markers, and reflector lenses on any car where you want protection without a tint.

Features and specifections

  • Clear and glossy, so it protects the lens without changing its look or dimming the light.
  • Resists yellowing and hazing, so the lens stays clear instead of clouding over time.
  • Takes the stone chips, gravel, bug splatter, and grit that pit an unprotected lens.
  • Blocks UV that fades and yellows the factory lens coating.
  • Self-healing top coat: light scratches and wash swirls fade out with heat from a gun, hot water, or the sun. (confirm this film self-heals, see earlier note)
  • Goes on dry, with air-release channels that push trapped air out for a bubble-free, crease-free finish.
  • Paper backing peels cleanly and helps you position the film before it grips.
  • Clear acrylic adhesive slides and repositions while you work, then holds firm once set.
  • A warm pass helps it wrap the curved edges of a lens; post-heating helps it stay down.
  • Wash with a mild, pH-neutral cleaner. Avoid wax and solvents.
  • Warm it to remove, and it peels without tearing.
  • Removal warning: on a lens that's already oxidized, yellowed, or has weak factory coating, peeling can lift the clear coat, so film lenses while they're still in good shape.
  • Fits headlights, fog lights, taillights, side markers, and reflector lenses.
  • Available in 1ft, 2ft, 4ft, 8ft, 16ft, and 32ft rolls, in a wide format that suits most headlights.
  • Lasts about a year on upright surfaces like headlight lenses.

Proper Installation

If the headlight surface is clean and undamaged before installation, the wrap adheres evenly and removes smoothly.

Proper Removal Technique

Using gentle heat (like a heat gun or hairdryer) softens the adhesive, making it easier to peel without pulling or tearing the headlight’s factory coating.

Warning

If the headlights are already oxidized, yellowed, or have weak factory coating, peeling the wrap can pull off clear coat or cause flaking.

Physical Properties

Classification Unit Spec Remark
Thickness Top protected film um 25±5 PE
Acrylic Adhesive um 20±2

Solvent-based

Face Film um 100±5 /

Release liner

um 180±2%  Paper Liner
Surface

-

- Glossy & Matte /
Width

-

cm 30/40±0.01% 1ft/1.3ft
Length

-

m 10±1% 32ft


Physical Performance

Features Test Method Results
Gloss (60°) GB 8807 92.3
VLT / 87%
Self-healing Layer Elongation at Break GB/T 1040.1 112
Face Film Elongation at Break GB/T 1040.1 309.5
Tear Strength GB/T529 92.7 KN/m
Tensile Strength GB/T 1040.1 21.6 Mpa
100% Modulus GB/T 1040.1 9.1 Mpa
Anti-yellowing / ΔE< 1.2
Light Transmission >40% 43%
Adhesive residue / <3%
Release force (N/25mm) paste on steel board, 90° 26℃ and 60%, GB2792 0.16
Initial tack (g/25mm) under 24℃ and 26%, GB31125-2014 860
Peel Strength (N/25mm) 180° 15
Holding power(h) paste on steel board, hang on by 25mm*25mm*1kg weight under 29℃ and 55%, GB/T4851-1998 No peel off within 48 hours
Aging Test  65℃ and 7 days No adhesive residue under 20 times wrapping
Application Temperature / +20℃ to +30℃
Service Temperature / -50℃ to +110℃
Recommended Shelf Life 72°F (22°C) and 50% RH 1 year
Durability / 1 year

Recommendations

Recommended application tools: Squeegee, buffer, knife, masking tape, heat gun, magnets, gloves, IRR thermometer, sprayer, towel, and installation liquid
Application method: Standard methods for Car Light Protection Film. Do not overstretch and overheat. Post heating is necessary.
Post-heating temperature: 110°C flat surfaces, 130°C curves and overlaps.
Aftercare: PH neutral. Avoid wax or solvents.

Important Notice

The physical properties of the product detailed in this document are based on tests that we believe to be reliable. They are intended only as a source of information and are given without guarantee. They do not constitute a warranty. Purchasers should independently assess the suitability of this material for their specific use prior to application.

Warranty, Limited Remedy, and Disclaimer

Unless an additional warranty is specifically stated on the applicable product packaging or literature, VinylFrog warrants that each product meets the applicable specifications at the time of shipment. We make no other warranties or conditions, express or implied, including but not limited to any implied warranty or condition of merchantability or fitness for a particular purpose, or any implied warranty or condition arising out of a course of dealing, custom, or usage of trade. If the VinylFrog product does not conform to this warranty, then based on our discretion, the sole and exclusive remedy is either the replacement of the product or a refund of the purchase price.

Limitation of Liability

Except where prohibited by law, VinylFrog will not be liable for any loss or damage arising from its product, whether direct, indirect, special, incidental or consequential, regardless of the legal theory asserted, including warranty, contract, negligence or strict liability.

Durability

The durability of the product is based on exposure conditions in South China. Actual performance life will depend on substrate preparation, exposure conditions, and maintenance of the product. For instance, in areas with excessively high temperature, industrial pollution, or high altitude, exterior performance will decrease.
